SKF MKU Series - Example Hydraulic Connection MKU

34
Exa
mpl
e for Hydraulic c
onnection
MKU, Fig.
8
4.3.6 Example hydraulic connection MKU
P
P
R
P
P
R
G1/4
0,5 bar
30 bar
G1/4
0,5 bar30 bar
20 bar
MKU x - 1xAX0x000+xxx
without optional Pressure gauge
without optional Fill level switch (NC)
without optional Pressure switch (20 bar)
with control unit A
for Oil lubricant
MKU x-1xEC1x000+xxx
with Pressure gauge
with Fill level switch (NC)
with Pressure switch (20 bar)
with control unit A
for Oil lubricant
EN
4. Assembly
