3. Overview
3.3 Order code for MKU gear pump units
Order code
M K U – 1 0 0 0 +
Product series MKx
U = Oil lubricant
Delivery rate
1 = 0.1 l/min • • • –
2 = 0.2 l/min – • • •
5 = 0.5 l/min – • • •
Delivery rate
Lubricant reservoir, control unit
Lubricant reservoir 1 2 3 4
2-liter plastic 3-liter plastic 3-liter metal 6-liter plastic
Control unit
A =
Without control unit, with terminal strip • • • •
B =
Without control unit, with terminal strip and
pushbutton
• • • •
C = IG38-30-I
1)
– • • •
D =
IZ38-30-I
1)
– • • •
E =
IGZ36-20-S6-I
1)2)
– • • •
Lubricant reservoir
Control unit
Monitoring
X A B C D E
Fill level switch
Without fill level switch • • – – – –
NC contact (
wire breakage
detection function)
– – • • – –
NO-contact (
without wire
breakage detection)
– – – – • •
Pressure switch 20 bar
Without pressure switch • – • – • –
NO-contact – • – • – •
Pressure gauge
0 = Without pressure gauge
1 = With pressure gauge
Monitoring
Pressure gauge
Electrical connection
