SKF MKU Series User Manual

31
4
G
e
ar pump u
nit with 3-lit
er
met
al
r
eservoir for oil and fl
uid
gre
ase,
Fig.
5
Clearance for lid removal
Assembly holes
4.3.3 MKU/MKF/MKL gear pump units with 3-liter metal reservoir for oil and fluid grease
286
(G1/4)
(G1/4)
B
A
C
Recommended fastening hardware:
o Hexagon head bolts (2x) acc. to
ISO 4017-M6x25-8.8
o Washers (4x) acc. to
ISO 7090- 6-200-HV
o Hexagon nuts (2x) acc. to
ISO 4032-M6-8
Tightening torque: 25 Nm
Minimum mounting dimensions
A = width: 390 mm
B = height: 400 mm
C = depth: 140 mm
