5.5 Control unit designs with their basic settings
Control unit: IG38-30-I
Operating instructions: 951-180-000-EN
Description: The IG38-30-I is used as a pulse generator.
Functions
• Adjustable interval time
• Interval time extension
• Pump cycle time limit
• Pressure build-up monitoring
• Fill level monitoring (NC contact)
Control unit: IZ38-30-I
Operating instructions: 951-180-000-EN
Description: The IZ38-30-I is used as a pulse counter.
Functions
• Adjustable interval time
• Pump cycle time limit
• Pressure build-up monitoring
• Fill level monitoring (NC contact)
IG38-30-I parameters, Table 1
Designation Default Unit Adjusted via Adjustment range Unit
Interval time 1 Minutes Rotary switch 1 - 2048 Minutes
in binary
increments
Monitoring time 60 Seconds Non-adjustable + 3000
Delay time 15 Seconds Non-adjustable + 4000
+ 5000
IZ38-30-I parameters, Table 2
Designation Default Unit Adjusted via Adjustment range Unit
Interval time 1 Pulses Rotary switch 1 - 2048 Pulses
in binary
increments
Monitoring time 60 Seconds Non-adjustable + 3000
Delay time 15 Seconds Non-adjustable + 4000
+ 5000
EN
5. Functional description
