SKF MKU Series - System Criteria for MKL Gear Pump Unit

66
Plug connectors for metal pipe, Fig. 36 Plug connectors for plastic pipe, Fig. 37
Metal tube 1
Plastic tube 1
Collet 4
Collet 4
First O-ring 2
First O-ring 2
Claw groove
Locking claw 5
Locking claw 5
Mechanical stop 3
Mechanical
stop 3
The MKL gear pump unit can be used for
oil+air centralized lubrication systems. In
this case, consult the corresponding assembly
instructions for the oil+air lubrication system
when assembling and designing the system.
The assembly instructions for the SKF OLA
oil+air system are 951-170-004-EN.
4.13 System criteria for MKL gear pump
unit
