80
Control unit: IGZ36-20-S6-I
Operating instructions:
951-180-001-EN
Description:
The IGZ36-20-S6-I device can be used as a pulse generator (operating mode B) and a pulse counter (operating mode D).
Functions
• Adjustable interval time
• Adjustable pump delay time
• Adjustable monitoring time
• Pump cycle time limit
• Pressure build-up monitoring
• Pressure reduction monitoring
• Fill level monitoring (NC contact)
Control unit: IG54-20-S4-I
Operating instructions:
951-180-001-EN
Description: The IG54-20-S4-I device can only be used as a pulse generator (operating mode B).
Functions
• Adjustable interval time
• Adjustable number of prelubrication cycles
• Adjustable pump delay time
• Pump cycle time limit
• Oil pressure monitoring
• Air pressure monitoring
• Fill level monitoring (NC contact)
• Non-volatile memory (EEPROM)
• Additional output d3 for compressed-air valve
IGZ36-20-S6-I parameters, Table 3
Designation Abbre- Default Unit Adjustment range Unit
viation
Operating mode BA B B (pulse generator)
D (pulse counter)
Interval time TP 10 Minutes 01 E 00 - 99 E 04 (BA B) Minutes
01 E 00 - 99 E 04 (BA D) Pulses
Monitoring time TU 60 Seconds 01 E 00 – 10 E 01 Seconds
Delay time TN 15 Seconds 01 E 00 – 30 E 00 Seconds
IG54-20-S4-I parameters, Table 4
Designation Abbre- Default Unit Adjustment range Unit
viation
Operating mode BA B Non-adjustable
Interval time TP 10 Minutes 01 E 00 - 99 E 00 Minutes
Monitoring time TU 60 Seconds Non-adjustable
Delay time TN 5 Seconds 00 E 00 – 99 E 00 Seconds
Prelubrication
cycles VZ 10 00 E 00 – 99 E 00
EN
5. Functional description
