Absolute Location displays the current location relative to a “power-on” location of (0,0):
o X is the left-to-right location
o Y is the up-&-down location
o L is the straight-line distance from (0,0)
Relative location displays the change in location currently being made as you press the arrow keys:
o x is the current left-to-right distance moved from X
o y is the current up-&-down distance moved from Y
o l is the straight-line distance from the (X,Y) location
• Up Speed is how fast the blade travels while in the “up” position, such as when it is moving from the origin
to the location of the first shape to cut or when moving from one cut shape to begin cutting another. When
turned off, Up Speed will match the SPEED set for cutting. Turning on this setting will change the
Speed/Force screen to display both speeds, allowing them to have different settings:
• To right power on: With this setting turned on, the cutting head will move to the far right whenever the
Skycut is powered on.
• Y Key Mode: This setting controls the movement of the material or cutting mat when using the up and down
arrows in the Main Screen:
