Skyjack SJ16 Service Manual

101
SJ12, SJ16
213558ADA
Battery Maintenance Section 5 – Procedures
5.7-4 Charger Error Codes
Fault
Code
Description Troubleshooting/Customer Actions
E-0-0-1
Battery voltage over limit in software. Typically
2.5V/cell. At the start of a charger cycle only and
only for lead acid batteries. It is acceptable for
the voltage to go above this during charging
and when charging Lithium batteries.
▪
Check the battery voltage and cable connections.
▪
Check charger voltage model is appropriate for
batteries.
▪
This error automatically clears once the condition has
been corrected.
E-0-0-2
Battery voltage too low to start a charge cycle.
Algorithm dependent. Typically 0.1V/cell.
▪
Check the battery voltage and cable connections.
▪
Check the charger is the correct voltage for the batteries
it is connected to.
▪
Check battery size and condition. Batteries may be
overdischarged. Use another charger to bring the
batteries above the minimum voltage.
▪
This error automatically clears once the condition has
been corrected.
E-0-0-3
Charge time limit reached. Algorithm
dependent.
▪
Charger output reduced due to high temperatures.
Operate at lower ambient temperature.
▪
Charger output reduced due to low AC voltages. Check
AC voltages.
▪
Check for shorted or damaged cells.
▪
Poor battery health. Replace the battery.
▪
Batteries too large for the charger. Replace batteries.
▪
Very deeply discharged battery. Retry charge.
▪
Battery connections are loose or corroded. Check
connections.
▪
Extra loads. Turn off other devices running on the battery
▪
This error automatically clears once the charger is reset
by cycling DC or by loss of AC for over 10 minutes.
E-0-0-4
Battery could not be trickle charged up to
the minimumvoltage. May also be used for
other battery-related errors depending on the
algorithm.
▪
Check for shorted or damaged cells.
▪
Poor battery health. Replace the battery.
▪
Check DC connections.
▪
May be caused because of output reduced due to high
temperature.
▪
Some new batteries may trigger these alarms as there
voltage dips
▪
when charging starts before it goes onto rise.
E-0-0-7
Charge amp-hour Limit reached. Algorithm
dependent.
▪
Charger output reduced due to high temperatures.
Operate at lower ambient temperature
▪
Charger output reduced due to low AC voltages. Check
AC voltage.
▪
Check for shorted or damaged cells.
▪
Poor battery health. Replace the battery.
▪
Very deeply discharged battery. Retry charge.
▪
Battery connections are loose or corroded. Check
connections.
▪
Extra loads. Turn off other devices running on the battery
▪
This error automatically clears once the charger is reset
by cycling
▪
DC or by loss of AC for over 10 minutes.

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
