Skyjack SJ16 - Wheel Brake and Port Identification

47
SJ12, SJ16
213558ADA
Wheel Brake and Port Identifications Section 3 – System Component Identification and Schematics
3.7 Wheel Brake and Port Identifications
M149106AA_S3
BH1
Wheel Brake (Right)
M1
Drive Motor (Right)
B
To Main Manifold
B
To Main Manifold
A
To Drive Motor (Left)
A
To Drive Motor (Right)
M2
Drive Motor (Left)
To Brake Manifold
BH2
Wheel Brake (Left)
To Brake Manifold
