Skyjack SJ16 - Elevate Telematics Harness

A B C D E F G H
V
Z
Y
X
W
66
SJ12, SJ16
213558ADA
3.26 Elevate Telematics Harness
M228562AD
JUMPER 228570
TO TELEMATICS UNIT
TO BATTERY NEGATVIE (-)
TO BATTERY POSITIVE (+)
1 AMP FUSE AND FUSE HOLDER
SUPPLIED WITH TRACK UNIT TELEMATICS
07
19E
19A
219D
MOTOR CONTACTOR
ATTACH RELAY TO HORN/CB ASSEMBLY
DISCARD JUMPER
NORMALLY CONNECTED
BASE CONTROL PANEL
YELLOW
D219D
CONNECTIONS FOR BMS
CONNECTIONS FOR CHARGER
CONNECT 19B, 18X, 17, 07, AND B+
TO BASE CONTROL TERMINALS
J1
B+
00
B+
1 A
19A
19E
CANL
CANH
SCH
SCL
SB+
S00
SB+1
00
CANH
B+
CANL
B+
219D
19B
17
07
18X
07
S07
