Skyjack SJ16 Service Manual

49
SJ12, SJ16
213558ADA
Platform Control Box Wiring Section 3 – System Component Identification and Schematics
3.9 Platform Control Box Wiring
M213344AD
9 PIN
JOYSTICK
CONNECTOR
CAVITY COLOUR CIRCUIT NO.
A10
WHITE/BLACK
16
A9
BLUE 15
A8 BLACK 14
A7
ORANGE 13
A6
BLUE/WHITE
08
A2
WHITE 02
A3 RED 07
B6
ORANGE/BLACK
59
B1
RED/WHITE
12A
B3
BLACK/WHITE
23
B4
BLUE/BLACK
24
B5
GREEN/WHITE
49
C10
GREEN/BLACK
19B
C9
RED/BLACK
19B
C8/C7/C6
JUMPER
07B
C1/C2/C3
GREEN 07A
C4/C5
JUMPER
19A
08A
08A
02
08A
49
15
A
13
16
12B
B
14
08B
02
07A
07
07A
08
JOYSTICK
S4 - EMERGENCY STOP
S8 - HORN
S3 - LIFT/OFF/DRIVE
19B19B
12A
DA
DB
D12B
PIN NO. LABEL DESCRIPTION CONTROL BOX HARNESS JOYSTICK HARNESS
1
24
LEFT
BLUE/BLACK WHITE/RED
2 12B
STEERING VS+
BROWN/RED WHITE/GREEN
3 23 RIGHT
BLACK/WHITE
WHITE
4
B
FWD/UP
RED YELLOW
5
08A JOYSTICK VS+
PURPLE/WHITE WHITE/BLACK
6 A
REV/DOWN PURPLE/WHITE
GREY
7
59 PROP. OUT
ORANGE/BLACK
BLUE
8 02 GND WHITE BLACK
9 08B ENABLE VS+
PURPLE/WHITE WHITE/BLUE

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
