Skyjack SJ16 Service Manual

29
SJ12, SJ16
213558ADA
Specifications and Features - ANSI/CSA Section 2 – Maintenance Tables and Diagrams
2.2 Specifications and Features - ANSI/CSATable
Model SJ12 SJ16
Weight * 863 kg (1905 Ib) 980 kg (2160 lb)
Overall Width 0.78 m (30.50 in) 0.78 m (30.50 in)
Overall Length 1.40 m (55.14 in) 1.40 m (55.14 in)
Platform Size (Inside)
0.68 m x 0.85 m
(26.96 in x 33.31 in)
0.68 m x 0.85 m
(26.96 in x 33.31 in)
Platform Traversing 0.41 m (16.00 in) 0.41 m (16.00 in)
Height
Working Height 5.49 m (18 ft) 6.58 m (21.7 ft)
Platform Elevated Height 3.66 m (12 ft) 4.75 m (15.7 ft)
Stowed Height 1.78 m (70.19 in) 1.78 m (70.19 in)
Drive Height Full Full
Lowered Platform Height 0.45 m (17.66 in) 0.45 m (17.66 in)
Standard Operating Times
Lift Time (Rated Load) 13 s - 16 s 16 s - 25 s
Lower Time (Rated Load) 13 s - 17 s 17 s - 19 s
Chassis
Normal Drive Speed
3.1 km/h - 4.0 km/h
(2.0 mph - 2.5 mph)
3.1 km/h - 4.0 km/h
(2.0 mph - 2.5 mph)
Elevated Drive Speed
0.6 km/h - 0.8 km/h
(0.4 mph - 0.5 mph)
0.6 km/h - 0.8 km/h
(0.4 mph - 0.5 mph)
Gradeability (Ramp Angle [Reverse/Forward])** 30% / 25% 30% / 25%
Tires (Solid Rubber) 309 mm x 100 mm (12 in x 4 in) 309 mm x 100 mm (12 in x 4 in)
Hydraulic Oil
Type ATF Dexron III ATF Dexron III
Tank Capacity 4.9 L (1.3 gal) 4.9 L (1.3 gal)
* Weights are approximate; refer to serial nameplate for specific weight.
** Refer to Section 6.4 Move the MEWP for Transport in the Operation manual for more details.
1835AB

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
