Skyjack SJ16 Service Manual

A B C D E F G H
V
Z
Y
X
W
56
SJ12, SJ16
213558ADA
3.16 Hydraulic Schematic
M216844AB
HYDRAULIC
RESERVOIR
F1
STRAINER
P1
SYSTEM PUMP
(3.59 CC / REV)
(0.219 CU. IN / REV)
R1
SYSTEM
RELIEF
3000 PSI
QD1
OPTION
TEST
PORT
P
T
MB1 POWERPACK
MANIFOLD
SAE 06
SAE
06
T
P1
4H-14A
LIFT
FC1
PRIORITY
STEERING
R2
STEER
RELIEF
1500 PS1
R3
LIFT RELIEF
2000 PSI (SJ12)
2700 PSI (SJ16)
2H-21
POTHOLE
RELEASE
MB2 MAIN MANIFOLD
SAE 04
PH
SAE 06
L
C2
LOWER LIFT
CYLINDER
2H-13
LOWER
MB4
HOLDING
MANIFOLD
O1
0.055'' (SJ12)
0.043'' (SJ16)
4H-24
LEFT
SL SR
SAE 04
SAE
04
C1
STEER
CYLINDER
2H-17
BRAKE
RELEASE
B
F
M2 M1
R
SAE 04
SAE
06
SAE
06
SAE
06
SAE
06
4H-16A
FORWARD
4H-15A
REVERSE
O2
0.031''
B
B
A
A
M2
LEFT DRIVE
MOTOR
M1
RIGHT DRIVE
MOTOR
CB1
4000 PSI
10:1
4H-23
RIGHT
C3
POTHOLE
CYLINDER
M
A=FORWARD
B=REVERSE
A=REVERSE
B=FORWARD
P2
BRAKE
HAND
PUMP
MB3
BRAKE MANIFOLD
BR1
RIGHT
BRAKE
BR2
LEFT
BRAKE
04SAE 04SAE
BRAKE
B1
V1
AUTO
RESET
BRAKE
OVERRIDE

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
