Skyjack SJ16 Service Manual

31
SJ12, SJ16
213558ADA
Maximum Platform Capacities (Evenly Distributed) ANSI/CSA Section 2 – Maintenance Tables and Diagrams
2.4 Maximum Platform Capacities (Evenly Distributed)
ANSI/CSA
Table
2.5 Maximum Platform Capacities (Evenly Distributed) CE,AS
Table
Model
Wind Rating
Total Platform
Capacity
Extension Platform
Capacity
Manual
Side Force
Tilt Cutout
Setting (side-
to-side x
front-to-back)
SJ12
Indoor
0 m/s
(0 mph)
227 kg
(500 lb)
2 person(s)
227 kg
(500 lb)
2 person(s)
400 N
(90 lbf)
1.5° x 3°
Outdoor
12.5 m/s
(28 mph)
1 person(s) 1 person(s)
200 N
(45 lbf)
SJ16
Indoor
0 m/s
(0 mph)
227 kg
(500 lb)
1 person(s)
227 kg
(500 lb)
1 person(s)
200 N
(45 lbf)
1.5° x 3°
Outdoor
Option
12.5 m/s
(28 mph)
2072AA
2073AA
Model
Wind Rating
Total Platform
Capacity
Extension Platform
Capacity
Manual
Side Force
Tilt Cutout
Setting (side-
to-side x
front-to-back)
SJ12
Indoor 0 m/s
227 kg
2 person(s)
227 kg
2 person(s) 400 N
1.5° x 3°
Outdoor 12.5 m/s 1 person(s) 1 person(s) 200 N
SJ16
Indoor 0 m/s
227 kg 1 person(s) 227 kg 1 person(s) 200 N 1.5° x 3°
Outdoor
Option
12.5 m/s
NOTE
Occupants and materials are not to exceed the rated load. Refer to the capacity label at the entrance of the
platform and the mast assembly for additional information and models equipped with options.
NOTE
Occupants and materials are not to exceed the rated load. Refer to the capacity label at the entrance of the
platform and the mast assembly for additional information and models equipped with options.

Skyjack SJ16 Specifications

General

Gradeability	25%
Drive Motor	24V DC
Max Gradeability	25%
Platform Height	16 ft
Lift Capacity	500 lbs
Machine Width	0.76 m
Overall Width	0.76 m
Drive Speed (Stowed)	4.8 km/h
Drive Speed (Raised)	0.8 km/h
Turning Radius (Inside)	0 in
Power Source	24V DC Electric
