70
213558ADA
SJ12, SJ16
Section 4 – Troubleshooting Information Electrical System Troubleshooting
17. Open or defective Idle/PLTF/Base Key switch
S10.
Select function with switch. Check continuity
between wire #5A and wire #08 on switch.
(Platform selected).Check continuity between wire
#5A and wire #07 on switch. (Base selected).
Replace switch if no continuity during correct
switch function.
18. Loose or broken B- cable wire #00 from batteries
to B- lug on Motor Controller.
Check continuity. Replace if defective.
19. Loose or broken wire #00 from Motor Controller
to Circuit Breaker CB2.
Check continuity. Replace if defective.
20. Defective or tripped circuit breaker CB2. Reset Circuit Breaker. Replace if defective.
21. Loose or broken wire #02 from Circuit Breaker
CB2 to Base terminal block.
Check continuity. Replace if defective.
