Chapter 4 Service Procedure
HRS Series 4.2 Work Procedure
4-3
Fig. 4.2-2 Removal of panels
 Mounting
Panel attachment is performed in inverse order of its removal.
2. Right side
panel
4. Front panel
3.Tank lid
3 . Pull out the connector from
the display board.
3.O-ring
