SMC Networks HRS012-A-10 Series - Discharge of the Circulating Fluid and Facility Water

HRX-MM-N007
Chapter 4 Service Procedure
4.2 Work Procedure HRS Series
4-4
4.2.2 Discharge of the circulating fluid and facility water
The following parts requires to discharge the circulating fluid. Follow the
procedure below. Discharge the circulating fluid before the replacement.
Table 4-1 Service parts which requires the discharge of the circulating fluid.
Description
Part number
Temperature sensor
HRS-S0007
Hose (For standard pump)(For HRS012/018/024)
HRS-S0008
Hose (For standard pump)(For HRS030)
HRS-S0302
Hose (For high pressure pump MT) (For HRS012/018/024)
HRS-S0069
Hose (For high pressure pump MT) (For HRS030)
HRS-S0304
Hose (For high pressure pump T) (For HRS012/018/024)
HRS-S0077
Hose (For high pressure pump T) (For HRS030)
HRS-S0303
Level switch
HRS-S0014
Pump (For 100V type)
HRS-S0022
Pump (For 200V type)
HRS-S0066
Pump (For HRS030)
HRS-S0361
High pressure pump (For 100V type option T)
HRS-S0265
High pressure pump (For 100V type option MT)
HRS-S0266
High pressure pump (For 200V type option T) (For HRS012/018/024)
HRS-S0062
High pressure pump (For 200V type option T) (For HRS030)
HRS-S0299
High pressure pump (For 200V type option MT)
HRS-S0063
High pressure pump (For 200V type option MT) (For HRS030)
HRS-S0300
Mechanical seal set (For 100V type option T) (For HRS012/018/024)
HRS-S0390
Mechanical seal set (For 100V type option MT) (For HRS012/018/024)
HRS-S0412
Mechanical seal set (For 200V type option T, MT)
HRG-S0211
Tank
HRS-S0025
Tank (For automatic water fill)
HRS-S0072
Valve for automatic water fill
HRS-S0071
 Stop the customer device and release the residual pressure before
discharging the circulating fluid.
 Before discharging the facility water, in case of water-cooled
refrigerated type, stop the equipment for the facility water, or stop
the facility water circuit to release the residual pressure.
