HRX-MM-N007
Chapter 4 Service Procedure
4.3 Check After Work HRS Series
4-8
4.3 Check After Work
After the work is completed, check the product can operate normally.
4.3.1 Starting the product
Press the [RUN/STOP] key on the operation panel.
 The [RUN] lamp lights up (in green) and the product starts running.
 The circulating discharge temperature (PV) is controlled to the set
temperature (SV).
Fig. 4.3-1 Starting the product
4.3.2 Stopping the product
1. Press the [RUN/STOP] key on the operation panel.
 The [RUN] lamp on the operation panel flashes green at 1 second intervals, and
continues operation to prepare to stop.
 After approx. 15 seconds, the [RUN] lamp goes off and the product stops.
Fig. 4.3-2 Stopping the product
2. Turn off the power supply switch.
All LEDs go off.
Press
ON
Press
Flash
OFF
