SMC Networks HRS012-A-10 Series User Manual

HRX-MM-N007
Chapter 5 Service Parts List
HRS Series 5.3 Illustration of Service Parts
5-5
5.3.3 Temperature sensor
Fig. 5.3-3 Temperature sensor
Table 5-4 Part number of service parts (Temperature sensor)
Description
Part number
Temperature sensor
HRS-S0007
5.3.4 Hose
Fig. 5.3-4 Hose
Table 5-5 Part number of service parts (Hose)
Description
Part number
Hose (For standard pump)
HRS-S0008
Hose (For standard pump)(For HRS030)
HRS-S0302
Hose (For high pressure pump MT)
HRS-S0069
Hose (For high pressure pump MT)(For HRS030)
HRS-S00304
Hose (For high pressure pump T)
HRS-S0077
Hose (For high pressure pump T)(For HRS030)
HRS-S0303
