Chapter 4 Service Procedure
4.4 Icons for Necessary Tools and Specifications HRS Series
4-10
4.4 Icons for Necessary Tools and Specifications
 Tools necessary for service
Table 4-2 Tools necessary for service
Description
Icon
Content
Spanner/Wrench
Flat size: 9mm
Flat size: 8mm
Flat size:10mm
Flat size: 17mm
Flat size: 21mm
Flat size: 24mm
Drain pan
Height:Max.100mm
Nippers
-
Pliers
-
Cross recessed
screwdriver
(1)
Total length:
Max. 200mm
-
flat blade
screwdriver(1)
-
Long-nose plier
-
Hexagon wrench
Flat size: 2mm
Flat size: 5mm
Silicone sealant
Recommended：HRG-S0214
Drying time: 2 hours
(1) Screwdriver with magnetic tip.
