HRX-MM-N007
Chapter 4 Service Procedure
4.5 Replacement Procedure HRS Series
Be sure to shut off the breaker of the facility power supply (the user’s
machine power supply) before replacement work.
4.5.21 Replacement of valve for automatic water fill
＜HRS-A/W-J＞
Table 4-28 Part number of service parts (Valve for automatic water fill)
Valve for automatic water fill
Removal
1. Remove the upper panel and the side panel on the right referring the 4.2.1 Removal and
the mounting of the panel.
2. Remove the cable connector of valve from the main board.
[Tips]
Use “57031-6000” of MOLEX for removing.
Our part no.：HRS-S0056
3. The hose mounted on valve for automatic water fill is removed.
4. Remove the valve for automatic water fill.
