Chapter 5 Service Parts List
5.2 Service Parts List HRS Series
5-2
5.2 Service Parts List
1.4.1 Check the part number referring the model number label and 5.1.1 Numbering system. Select the
part number of the service part from confirmed part number and service part number.
Table 5-1 Service parts list
Description
Part no.
Product part no.
Reference page
Dustproof filter
HRS-S0001
HRS series common part
5-4
Apper panel
HRS-S0002
HRS series common part
5-4
Right side panel
HRS-S0003
HRS series common part
(Except option G/HRS030)
5-4
Right side panel (For option G)
HRS-S0075
For option G/HRS030 (Vent hole)
5-4
Left side panel
HRS-S0004
HRS series common part
(Except option G/HRS030)
5-4
Left sade panel (For option G)
HRS-S0076
For option G/HRS030 (Vent hole)
5-4
Front panel
HRS-S0519
HRS series common part
From production in March 2015
(After serial No. TQ***)
5-4
Front panel B
HRS-S0005
HRS series common part
Until production in February 2015
(Serial No. TP*** or earlier)
5-4
Front panel A
HRS-S0006
HRS series common part
Until production in February 2015
(Serial No. TP*** or earlier)
5-4
Temperature sensor
HRS-S0007
HRS series common part
5-5
Hose (For standard pump)
HRS-S0008
For standard pump
(For HRS012/018/024)
5-5
Hose (For standard pump)
HRS-S0302
For standard pump(For HRS030)
5-5
Hose (For high pressure pump MT)
HRS-S0069
Option MT: High pressure pump
(For HRS012/018/024)
5-5
Hose (For high pressure pump MT)
HRS-S0304
Option MT: High pressure pump
(For HRS030)
5-5
Hose (For high pressure pump T)
HRS-S0077
Option T: High pressure pump
(For HRS012/018/024)
5-5
Hose (For high pressure pump T)
HRS-S0303
Option T: High pressure pump
(For HRS030)
5-5
Pressure sensor (For circurating fluid)
HRS-S0011
HRS series common part
5-6
Level switch
HRS-S0014
HRS series common part
5-6
DC power supply
HRS-S0016
HRS series common part
5-7
Display board
HRS-S0520
HRS series common part
From production in March 2015
(After serial No. TQ***)
5-8
Display board
HRS-S0017
HRS series common part
Until production in February 2015
(Serial No. TP*** or earlier)
5-8
Communication board
HRS-S0018
HRS series common part
5-8
Power board
HRS-S0019
HRS series common part
5-8
Power switch (For 10A type)
HRS-S0020
200V type
(Except high pressure pump)
5-9
Power switch (For 15A type)
HRS-S0070
100V type
200V type high pressure pump
5-9
Inlet socket
HRS-S0021
HRS series common part
5-9
Pump (For 100V type)
HRS-S0022
Standard pump for 100V
5-10
Pump (For 200V type)
HRS-S0066
Standard pump for 200V
5-10
Pump (For HRS030)
HRS-S0361
Standard pump for HRS030
5-10
High pressure pump
(For 100V type option T)
HRS-S0265
100V type
Option T:High pressure pump
5-10
High pressure pump
(For 100V type option MT)
HRS-S0266
100V type
Option MT:High pressure pump
5-10
High pressure pump
(For 200V type option T)
HRS-S0062
200V type
Option T:High pressure pump
(For HRS012/018/024)
5-10
High pressure pump
(For 200V type option T)
HRS-S0299
200V type
Option T:High pressure pump
(For HRS030)
5-10
High pressure pump
(For 200V type option MT)
HRS-S0063
200V type
Option MT:High pressure pump
(For HRS012/018/024)
5-10
High pressure pump
(For 200V type option MT)
HRS-S0300
200V type
Option MT:High pressure pump
(For HRS030)
5-10
Mechanical seal set
(For 100V type option T)
HRS-S0390
100V type
Option T:High pressure pump
5-10
Mechanical seal set
(For 100V type option MT)
HRS-S0412
100V type
Option MT:High pressure pump
5-10
Mechanical seal set
(For 200V type option T,MT)
HRG-S0211
200V type
Option T,MT:High pressure pump
5-10
Fan (For 100V type)
HRS-S0023
For 100V fan
5-10
Fan (For 200V type)
HRS-S0067
For 200V fan
5-10
Fan (For HRS030)
HRS-S0301
For HRS030 fan
5-10
