HRX-MM-N007
Chapter 4 Service Procedure
HRS Series 4.5 Replacement Procedure
Be sure to shut off the breaker of the facility power supply (the user’s
machine power supply) before replacement work.
4.5.6 Replacement of fan
＜HRS-A-＞
Table 4-13 Part number of service parts (Fan)
Removal
1. Remove the upper panel and the panels on both sides referring the 4.2.1 Removal and the
mounting of the panel.
2. Remove the fan motor pin from the connector of the compressor cable. (2 pcs.)
[Tips]
Use VLJ-20 of J.S.T. Mfg. Co.,Ltd for removing pins.
Our part no.：HRS-S0055
3. Remove the ground wire(G5). (Screw ×1)
4. Remove the condenser. (Screw ×1)
5. Remove the fan . (Screw×4)
For the HRS030, cut the cable ties of the pump cable (1 place) and the compressor cable
(5 places) fixed to the fan motor bracket.
To Next Page
