Chapter 4 Service Procedure
4.5 Replacement Procedure HRS Series
4-28
BK is black, BL is blue.
Fig. 4.5-12 Removal of fan
5. Screw
4. Condenser
5. Screw
5. Screw
5. Fan
Fanmotor
cable
3. Ground wire (G5)
2. Compressor
connector
Fanmotor
bracket
5. Pump
cable
5. Compressor cable
[For HRS030]
