SMC Networks HRS012-A-10 Series User Manual

HRX-MM-N007
Chapter 3 Alarm Indication and Troubleshooting
3.3 Troubleshooting HRS Series
3-6
3.3.2 Icons for necessary tools and specifications
■ Tools necessary for troubleshooting
Table 3-3 Tools necessary for troubleshooting
■ Recommended protective tools
Table 3-4 Recommended protective tools
■ Tightening torque
Table 3-5 Tightening torque
Icon
Content
The number shows torque.
■ Removable panels
Table 3-6 Panel Icon
Icon
Content
 Removable panels
The panels that can be removed for part check are
shaded in the illustration.
See section 3.3.3 “Attachment and removal of panel” for details.
Description
Icon
Gloves
Goggles
Safety
shoes
Removable
panels
Description
Icon
Content
Cross recessed
screwdriver

1
－
Flat blade
screwdriver

1
－
Spanner/Wrench
Flat size: 14mm
Tester
For current/ frequency
measurement
[Required
measurement range]:
0 to 500V, 0 to 100kΩ
1: Screwdriver with magnetic tip.
