Chapter 4 Service Procedure
HRS Series 4.5 Replacement Procedure
4-51
 Mounting
1. Mount the power board. (screw ×2)
2. Mount the connector of power board. (5 locations)
3. Mount the upper panel and the side panel on the right in reversed order of removal.
