SMC Networks HRS012-A-10 Series User Manual

HRX-MM-N007
Chapter 6 Documents
HRS Series 6.1 Specifications List
6-3
Table 6-3 Specifications List (HRS0--20-(BGJMT))
Model
HRS012-W
-20-（BGJMT）
HRS018-W
-20-（BGJMT）
HRS024-W
-20-（BGJMT）
HRS030-W
-20-（BJMT）
Cooling method
Water-Cooled refrigerated type
Refrigerant
R407C(HFC)
Control method
PID control
Ambient temperature and humidity

1
Temperature ：5 to 40
o
C, Humidity：30 to 70%
Circulating fluid system
Circulating fluid

2
Tap water, Ethylene glycol aqueous solution 15%

4
Operating temperature
range

1
o
C
5 to 40
Cooling capacity

3
(50/60Hz)
W
1100/1300
1700/1900
2100/2400
2600/3200
Temperature stability

5
o
C
±0.1
Pump capacity

6
(50/60Hz)
MPa
0.13(at 7L/min)/0.18(at 7L/min)
For option -T： 0.44(at 10L/min)/0.40(at 14L/min)
For option -MT： 0.32(at 10L/min)/0.32(at 14L/min)
Rated fiow

7
(50/60Hz)
L/min
7/7
For option -T： 10/14, For option -MT： 10/14
Tank capacity
L
Approx. 5
Port size
Rc1/2
Wetted material
Stainless steel, Copper brazing (Heat exchanger)

14
, Bronze

14
Brass

14,
SIC, Aluminum oxide ceramic, Carbon, PP, PE, POM, FKM, EPDM, PVC
Facility water
outlet system

1
Temperature range
o
C
5 to 40
Pressure range
MPa
0.3 to 0.5
Required flow

12
L/min
8
12
14
15
Facility water pressure
differential
MPa
0.3 more
Port size
Rc3/8
Wetted material
Stainless steel, Copper brazing, Bronze, Synthetic rubber
Automatic fluid filling

14
Feed water pressure
range
MPa
0.2 to 0.5
Feed water temperature
range
o
C
5 to 40
Feed water capacity
L/min
Approx.1
Automatic fluid filling Port size
Rc3/8
Over flow port Port size
Rc3/4
Electric system
Power supply
1-phase AC200 to 230V 50/60Hz. Allowable voltage range ±10%
Circuit protector

16
A
10 (For option -T, -MT: 15)
Applicable earth leakage
breaker capacity

8
A
10 (For option -T, -MT: 15)
Rated operating current

3
(50/60Hz)
A
4.6/5.1
For option –T, -MT :
5.6/6.7
4.7/5.2
For option -T, -MT :
5.7/6.8
5.1/5.9
For option -T, -MT :
6.1/7.5
5.2/6.0
For option -T, -MT :
6.2/7.6
Rated power
consumption

3
(50/60Hz)
kVA
0.9/1.0
For option -T, -MT :
1.1/1.3
0.9/1.0
For option -T, -MT :
1.1/1.4
1.0/1.2
For option -T, -MT :
1.2/1.5
1.0/1.2
For option -T, -MT :
1.2/1.5
Noise level

9
(50/60Hz)
dB
60/61
62/65
Dimensions

10
mm
W377xD500xH615 (W14.8XD19.7xH24.2[Inch])
W377xD500xH660
(W14.8XD19.7xH26.0[In
ch])
Accessory
Fitting (for drain port) 1pc.

15
, Sequence I/O command
signal connector 1pc., Power supply connector 1pc., Operation manual (Installatio･Operation ) 1pc,
Quick manual (with a clear cover) 1pc., Alarm code list label 1pc.
Weight

11
kg
43
1 Use the product in conditions where freezing will not occur.
Consult with SMC if using in a season or region where the ambient temperature will fall below zero.
2 If tap water is used, use water which satisfies the standard of The Japan Refregeration And Air Conditioning Industry Association (JRA GL-02-1994/Cooling
water system - circulation type - make-up water)
3 (1)Operating ambient temp.: 25°C, (2)Circulating fluid temp.: 20°C, (3)Circulating fluid rated flow, (4)Criculating fluid : Tap water,(5)Facility water temp.: 25°C.
The cooling capacity will be reduced by 300W when option T and MT [High pressure pump] are selected.
4 Use a 15% ethylene glycol aqueous solution if operating in a place where the circulating fluid temp. is lower than 10
o
C.
5 Outlet temp. when the circulating fluid flow is rated flow, and the circulating fluid outlet and the return are directly connected. Installation environment and
power supply are within specification range and stable.
6 The capacity at the thermo-chiller outlet when the circulating fluid temp. is 20°C.
7 Fluid flow to maintain the cooling capacity and the temperature stability.
The specification of the coolong capacity and the temperature stability may not be satisfied if the flow rate is lower than the rated flow.
8 To be prepared by the customer. Use an earth leakage breaker with sensitivity of 30mA/200V in power supply specification..
9 Front 1m/Height 1m/Static with no load. See note 4 for other conditions.
10 Dimension between panels. Projection is not included.
11 Weight when the circulating fluid and facility water (for water-cooled type) is not included.
The weight will increase by 1kg when option J [Automatic fluid filling] is selected.The weight will increase by 6kg when option T and MT [High pressure pump] are selected.
12 There is required flow when adding load described on cooling capacity in case of note3 conditions.
13 For option J [Automatic fluid filling port].
14 Copper, bronze and brass are not included when option M [DI water piping] is selected
15 This fitting is not included when option T and MT [High pressure pump] are selected.
16 If option “Earth leakage breaker type” is selected, the earth leakage breaker is used instead of the circuit protector.
