Snapmaker A150 - Flat End Mill

User Manual |
144
CNC Carving - 03 Tool Library
Ball End Mill
Features a round cutting edge, typically used for cutting
curvatures and 3D shapes into materials.
3.3
Caving V-bit
Features a narrow and sharp tip, used for carving intricate,
detail-rich patterns.
3.4
Straight Groove V-bit
Features a long and sharp carving edge, can penetrate deep
into material and rendering high-precision creations.
3.5
The data sheets provided in this manual are intended for reference and comparison purposes only. Actual
performance varies with carving conditions. Each user is responsible for judging the tness for application in specic
conditions. The data is subject to change without notice.
3.2 Flat End Mill
Flat End Mill (Double Cut)
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Cutting Diameter (D1)
38 mm 12 mm 3.175 mm 3.175 mm
