Snapmaker A150 - Ball End Mill

User Manual |
145
CNC Carving - 03 Tool Library
Flat End Mill (Double Cut)
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Cutting Diameter (D1)
38 mm 12 mm 3.175 mm 3.175 mm
Flat End Mill (Single Cut)
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Cutting Diameter (D1)
38 mm 12 mm 3.175 mm 3.175 mm
3.3 Ball End Mill
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Cutting Diameter (D1)
38 mm 17 mm 3.175 mm 3 mm
