Snapmaker A150 - Caving V-Bit; Straight Groove V-Bit

User Manual |
146
CNC Carving - 03 Tool Library
3.4 Caving V-bit
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Tip Diameter (D1) Included Angle (A)
32 mm 5.5 mm 3.175 mm 0.2 mm 30°
3.5 Straight Groove V-bit
Total Length (L) Cutting Edge Length (L1) Shank Diameter (D) Tip Diameter (D1) Included Angle (A)
50 mm 24 mm 3.175 mm 0.3 mm 20°
