6-24
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
RB503 1-234-383-21 RES, NETWORK 470KX4 (1005)
RB504 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB505 1-239-686-11 RESISTOR, NETWORK 1K
RB506 1-234-378-21 RES, NETWORK 10KX4 (1005)
(TR618/TR618E/TR718E/TR728E/TR818)
RB508 1-239-686-11 RESISTOR, NETWORK 1K
RB509 1-239-657-81 RESISTOR, NETWORK 470K
RB510 1-234-375-21 RES, NETWORK 1KX4 (1005)
RB511 1-234-383-21 RES, NETWORK 470KX4 (1005)
RB514 1-239-706-81 RESISTOR, NETWORK 47K
< TRANSFORMER >
T001 1-435-252-11 TRANSFORMER, DC-DC CONVERTER
< VARISTOR >
VDR701 1-803-974-21 VARISTOR, CHIP
VDR703 1-803-974-21 VARISTOR, CHIP
VDR704 1-803-974-21 VARISTOR, CHIP
VDR706 1-803-974-21 VARISTOR, CHIP
VDR707 1-803-974-21 VARISTOR, CHIP
< VIBRATOR >
X271 1-760-320-11 VIBRATOR, CRYSTAL (28.636363MHz)
(TR618/TR818/TRV49/TRV58/TRV68/TRV78/TRV88/TRV98)
X271 1-760-321-11 VIBRATOR, CRYSTAL (28.375MHz)
(TR618E/TR718E/TR728E/TRV49E/
TRV58E/TRV59E/TRV78E/TRV98E)
X401 1-760-655-41 VIBRATOR, CRYSTAL (20MHz)
X501 1-767-980-21 VIBRATOR, CERAMIC (20MHz)
X502 1-760-458-21 VIBRATOR, CRYSTAL (32.768kHz)
************************************************************
A-7073-838-A VF-129 (N) BOARD, COMPLETE
(EXCEPT TR818)
**************************************
(Ref.No.;1000 Series)
< CAPACITOR >
C901 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C902 1-163-038-11 CERAMIC CHIP 0.1uF 25V
C903 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C904 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C905 1-104-752-11 TANTAL. CHIP 33uF 20% 6.3V
C906 1-162-638-11 CERAMIC CHIP 1uF 16V
C907 1-104-563-11 FILM CHIP 0.1uF 5% 16V
C908 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C909 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
0C910 1-162-625-11 CERAMIC CHIP 0.0047uF 5% 50V
0C911 1-164-715-11 CERAMIC CHIP 0.0068uF 5% 50V
C912 1-107-854-11 TANTAL. CHIP 68uF 20% 6.3V
C913 1-135-145-11 TANTALUM CHIP 0.47uF 10% 35V
C914 1-113-984-11 TANTAL. CHIP 1.5uF 20% 35V
C915 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C916 1-135-475-91 CERAMIC CHIP 0.001uF 10% 630V
< CONNECTOR >
* CN901 1-785-379-01 CONNECTOR, FFC/FPC 4P
* CN902 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< DIODE >
D901 8-719-951-21 DIODE PR1102W-TR
D903 8-719-073-01 DIODE MA111-(K8).S0
< IC >
IC901 8-759-196-14 IC BA7149F-E2
< COIL >
L901 1-412-031-11 INDUCTOR CHIP 47uH
L902 1-410-387-11 INDUCTOR CHIP 33uH
0 L903 1-411-697-11 COIL, FERRITE (HLC)
< TRANSISTOR >
Q901 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
Q902 8-729-106-68 TRANSISTOR 2SD1615-T1GLGK
Q903 8-729-216-31 TRANSISTOR 2SA1163G-TE85L
Q904 8-729-230-63 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R901 1-216-817-11 METAL CHIP 470 5% 1/16W
R902 1-216-817-11 METAL CHIP 470 5% 1/16W
R903 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R904 1-216-833-11 METAL CHIP 10K 5% 1/16W
R905 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R906 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R907 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-852-11 METAL CHIP 390K 5% 1/16W
R909 1-216-833-11 METAL CHIP 10K 5% 1/16W
R910 1-216-835-11 METAL CHIP 15K 5% 1/16W
R911 1-216-160-00 RES-CHIP 27 5% 1/8W
R912 1-216-857-11 METAL CHIP 1M 5% 1/16W
R915 1-218-879-11 METAL CHIP 22K 0.5% 1/16W
R917 1-218-891-11 METAL CHIP 68K 0.5% 1/16W
R918 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R919 1-216-843-11 METAL CHIP 68K 5% 1/16W
R920 1-216-837-11 METAL CHIP 22K 5% 1/16W
R921 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R921 1-216-800-11 RES-CHIP 18 5% 1/16W
R922 1-216-850-11 METAL CHIP 270K 5% 1/16W
R923 1-216-857-11 METAL CHIP 1M 5% 1/16W
R924 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R925 1-216-862-11 RES-CHIP 2.7M 5% 1/16W
R926 1-216-821-11 METAL CHIP 1K 5% 1/16W
R927 1-216-821-11 METAL CHIP 1K 5% 1/16W
R928 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R929 1-216-821-11 METAL CHIP 1K 5% 1/16W
R930 1-216-791-11 METAL CHIP 3.3 5% 1/16W
R931 1-217-671-11 METAL CHIP 1 5% 1/10W
R932 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< VARIABLE RESISTOR >
RV903 1-238-852-11 RES, ADJ, CERMET 470
RV904 1-238-095-11 RES, ADJ, CERMET 470K
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
VC-251 VF-129
To Next Page
