Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSFORMER >
0 T901 1-453-124-11 TRANSFORMER ASSY, FLYBACK
T902 1-431-915-11 TRANSFORMER ASSY, FLYBACK (M)
< FLAT CABLE >
0 W901 1-540-019-21 SOCKET ASSY, CRT
************************************************************
A-7074-193-A VF-141 BOARD, COMPLETE (TR818)
*****************************
(Ref.No.;10000 Series)
< CAPACITOR >
C4501 1-127-688-21 TANTAL. CHIP 10uF 20% 6.3V
C4501 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C4503 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4504 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4507 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4508 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4509 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C4510 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4511 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C4512 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4513 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4514 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C4515 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
C4516 1-162-928-11 CERAMIC CHIP 120PF 5% 50V
C4517 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4518 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4519 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4520 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C4521 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C4523 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C4524 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C4526 1-107-726-11 CERAMIC CHIP 0.01uF 10% 25V
C4527 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4501 1-764-526-11 CONNECTOR, FFC/FPC 18P
CN4502 1-750-630-11 CONNECTOR, FFC/FPC (ZIF) 16P
< DIODE >
D4502 8-713-102-80 DIODE 1T369-01-T8A
D4503 8-719-077-74 DIODE MA2S784008S0
D4504 8-719-077-74 DIODE MA2S784008S0
< FERRITE BEAD >
FB4502 1-500-329-21 FERRITE 0UH
FB4505 1-500-329-21 FERRITE 0UH
< IC >
IC4501 8-759-660-93 IC RB5P004AM1
IC4502 8-752-405-57 IC CXD3501AR-T4
< COIL >
L4501 1-469-525-91 INDUCTOR 10uH
L4504 1-412-949-21 INDUCTOR 6.8uH
< TRANSISTOR >
Q4504 8-729-037-52 TRANSISTOR 2SD2216J-QR(K8).SO
< RESISTOR >
R4505 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4507 1-218-895-11 METAL CHIP 100K 0.5% 1/16W
R4508 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4513 1-216-835-11 METAL CHIP 15K 5% 1/16W
R4515 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R4516 1-216-841-11 METAL CHIP 47K 5% 1/16W
R4517 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4518 1-216-837-11 METAL CHIP 22K 5% 1/16W
R4520 1-216-843-11 METAL CHIP 68K 5% 1/16W
R4521 1-216-857-11 METAL CHIP 1M 5% 1/16W
R4522 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4523 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4524 1-216-844-11 METAL CHIP 82K 5% 1/16W
R4525 1-216-838-11 METAL CHIP 27K 5% 1/16W
R4526 1-216-809-11 METAL CHIP 100 5% 1/16W
R4527 1-216-809-11 METAL CHIP 100 5% 1/16W
R4528 1-216-809-11 METAL CHIP 100 5% 1/16W
R4529 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4530 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4534 1-216-864-91 SHORT 0
R4542 1-216-864-91 SHORT 0
R4544 1-216-853-11 METAL CHIP 470K 5% 1/16W
R4545 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4546 1-216-845-11 METAL CHIP 100K 5% 1/16W
R4547 1-216-845-11 METAL CHIP 100K 5% 1/16W
************************************************************
ACCESSORIES
***********
1-467-574-21 REMOTE COMMANDER (RMT-708)
(TR728E/TRV49/TRV49E/TRV59E/
TRV78/TRV78E/TRV98/TRV98E)
1-467-574-73 REMOTE COMMANDER (RMT-708)
(TRV49E:E/TRV78E:E/TRV98E:E)
0 1-475-599-11 ADAPTOR, AC (AC-L10A)
(TR618/TR618E:E,HK,AUS/TR718E:AEP,UK/TR728E:AEP,UK/
TR818/TRV49:E,HK,JE/TRV49E:E,HK,AUS,JE/TRV58/
TRV58E/TRV59E/TRV68/TRV78:E,HK,JE/TRV78E/TRV88/
TRV98:US,CND,E,HK,JE,BR/TRV98E:AEP,UK,E,HK,AUS,JE)
0 1-475-599-71 ADAPTOR, AC (AC-L10A)
(TRV49:KR/TRV78:KR/TRV98:KR)
0 1-475-599-81 ADAPTOR, AC (AC-L10B)
(TR618E:CN/TRV49E:CN/TRV98E:CN)
Note :
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Note :
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
