Sony DCR-TRV620E - Page 130

4-121
IC1301 2 REC/PB
1 Vp-p
r;
IC1301 rs REC/PB
440 kHz
440 kHz
5.2 Vp-p
ra
IC1301 rg REC/PB
440 kHz
1 Vp-p
rs
IC1301 rh REC/PB
440 kHz
1 Vp-p
rd
IC1301 t; REC/PB
440 kHz
1.36 Vp-p
rf
IC1301 tf REC/PB
440 kHz
5.2 Vp-p
rg
IC1301 tj REC/PB
440 kHz
1 Vp-p
rh
IC4902 1 REC/PB
20 MHz
1.96 Vp-p
ef
IC4902 <zzb PB (Hi8/Std8)
0.87 msec
1.96 Vp-p
eg
IC4401 tj, tl, ya REC/PB (Digital8)
450 Hz
3.1 Vp-p
eh
IC4401 tj, tl, ya PB (Hi8/Std8)
NTSC: 180 Hz
PAL: 150 Hz
1.4 Vp-p
eh
IC4401 qh REC/PB (Digital8)
450 Hz
2.8 Vp-p
ej
IC4401 qh PB (Hi8/Std8)
NTSC: 180 Hz
PAL: 150 Hz
2.8 Vp-p
ej
IC4401 ws PB (Hi8/Std8)
NTSC: 30 Hz
PAL: 25 Hz
2.8 Vp-p
ek
IC4401 ws REC/PB (Digital8)
75 Hz
2.8 Vp-p
ek
IC4401 wl REC/PB
12.7 usec
0.1 Vp-p
el
1
IC105 <znz MEMORY REC/PB
25.8048 MHz
1.5 Vp-p
PC-77 BOARD
