Sony DCR-TRV620E - Page 131

4-122
16.7 msec
IC901 1, 5 REC/PB
2 Vp-p
1.1 Vp-p
1
16.7 msec
IC901 3 REC/PB
2 Vp-p
2
16.7 msec
IC901 7 REC/PB
3
H
IC901 qa REC/PB
0.9 Vp-p
4
H
IC901 qd REC/PB
2.5 Vp-p
5
H
IC901 qh REC/PB
2.4 Vp-p
6
2H
IC4501 w; REC/PB
7 Vp-p
7 Vp-p
1
2H
B/W EVF MODEL
B/W EVF MODEL
COLOR EVF MODEL
COLOR EVF MODEL
COLOR EVF MODEL
COLOR EVF MODEL
COLOR EVF MODEL
COLOR EVF MODEL
IC4501 w;, ws, wf REC/PB
7 Vp-p
1, 2, 3
4, 5, 6
2H
IC4501 ws REC/PB
7 Vp-p
2
2H
IC4501 wf REC/PB
3
H
IC4501 rh REC/PB
400 mVp-p
H
IC4501 rh, rj, rk REC/PB
400 mVp-p
4
H
IC4501 rj REC/PB
400 mVp-p
5
H
IC4501 rk REC/PB
400 mVp-p
6
11 MHz
IC4502 wh REC/PB
2.6 Vp-p
7
H
IC3901 ra REC/PB (IR ON)
608 mVp-p
1
VF-129 BOARD VF-141 BOARDMI-37 BOARD
