4. C Page Table
Note 1: Fixed data-1: Initialized data. (Refer to “1. Initializing the
8, C, D Page Data”)
Note 2: Fixed data-2: Modified data. (Refer to “2. Modification
of 8, C, D Page Data”)
Address
Initial value
Remark
NTSC PAL
D6 Fixed data-2
D7
D8
D9
DA
DB
DC
DD
DE
DF
E0
E1 to E5 Fixed data-1 (Initialized data)
E6 Fixed data-2
E7 Fixed data-1 (Initialized data)
E8 08 08 Node unique ID No. input
E9 00 00
EA 46 46
EB 01 01
EC 01 01
ED 00 00
EE 00 00
EF 00 00
F0 to F3 Fixed data-1 (Initialized data)
F4 00 00 Emergency memory address
F5 00 00
F6 00 00
F7 00 00
F8 00 00
F9 00 00
FA 00 00
FB 00 00
FC 00 00
FD 00 00
FE 00 00
FF 00 00
Address
Initial value
Remark
NTSC PAL
00 to 0F
10 EE EE Switching position adj.
11 00 00
12 00 00
13 00 00
14 to 16 Fixed data-1 (Initialized data)
17 E0 E0 Reel FG adj.
18 25 25 APC & AEQ adj.
19 25 25
1A Fixed data-1 (Initialized data)
1B 25 25 APC & AEQ adj.
1C 25 25
1D Fixed data-1 (Initialized data)
1E 25 25 AGC center level adj.
1F 3E 3E PLL f
0
& LPF f
0
adj.
20 3E 3E
21 CA CA APC & AEQ adj.
22 99 99 PLL f
0
& LPF f
0
adj.
23, 24 Fixed data-1 (Initialized data)
25 88 88 S VIDEO OUT Y level adj.
26 E3 E3 S VIDEO OUT chroma level adj.
27 A1 A1
28 04 04 Chroma BPF f
0
adj.
29 20 20 PLL f
0
& LPF f
0
adj.
2A, 2B Fixed data-1 (Initialized data)
2C 03 03 APC & AEQ adj.
2D, 2E Fixed data-1 (Initialized data)
2F Fixed data-2
30 E0 E0 Reel FG adj.
31 to 41 Fixed data-1 (Initialized data)
42 Fixed data-2
43 to 83 Fixed data-1 (Initialized data)
84 Fixed data-2
85 Fixed data-1 (Initialized data)
86 Fixed data-2
87, 88 Fixed data-1 (Initialized data)
89 Fixed data-2
8A to 91 Fixed data-1 (Initialized data)
92 Fixed data-2
93 to 99 Fixed data-1 (Initialized data)
9A Fixed data-2
9B to A4 Fixed data-1 (Initialized data)
A5 Fixed data-2
A6
A7 to D5 Fixed data-1 (Initialized data)
