Note 3: LCD TYPE S/LCD TYPE C
5. D Page Table
Note 1: Fixed data-1: Initialized data. (Refer to “1. Initializing the
8, C, D Page Data”)
Note 2: Fixed data-2: Modified data. (Refer to “2. Modification
of 8, C, D Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to 0F
10 00 00 Test mode
11, 12 Fixed data-1 (Initialized data)
13 Fixed data-2
14
15 to 1A Fixed data-1 (Initialized data)
1B Fixed data-2
1C Fixed data-1 (Initialized data)
1D Fixed data-2
1E
1F
20 to 26 Fixed data-1 (Initialized data)
27 Fixed data-2
28
29 to 2B Fixed data-1 (Initialized data)
2C Fixed data-2
2D to 2F Fixed data-1 (Initialized data)
30 Fixed data-2
31 to 42 Fixed data-1 (Initialized data)
43 Fixed data-2
44
45
46, 47 Fixed data-1 (Initialized data)
48 90 90 Battery end adj.
49 98 98
4A to 4C Fixed data-1 (Initialized data)
4D Fixed data-2
4E to 50 Fixed data-1 (Initialized data)
51 Fixed data-2
52 Fixed data-1 (Initialized data)
53 Fixed data-2
54 to 59 Fixed data-1 (Initialized data)
5A Fixed data-2
5B
5C
5D to 65 Fixed data-1 (Initialized data)
66 Fixed data-2
67
68
69
6A to 83 Fixed data-1 (Initialized data)
84 Fixed data-2
85, 86 Fixed data-1 (Initialized data)
87 Fixed data-2
88 to 8D Fixed data-1 (Initialized data)
8E Fixed data-2
8F
Address
Initial value
Remark
NTSC PAL
90, 91 Fixed data-1 (Initialized data)
92 80 80 VCO adj. (LCD EVF)
93 – 70 Fixed data-1 (NTSC model) /
VCO adj. (LCD EVF) (PAL model)
94 Fixed data-1 (Initialized data)
95 A0 A0 RGB AMP adj. (LCD EVF)
96 Fixed data-1 (Initialized data)
97 80 80 White balance adj. (LCD EVF)
98 80 80
99 30 30 Contrast adj. (LCD EVF)
9A, 9B Fixed data-1 (Initialized data)
9C D0 D0 Backlight consumption current adj.
9D 10 10 (LCD EVF)
9E 10 10
9F to A1 Fixed data-1 (Initialized data)
A2 80 80 VCO adj. (LCD)
A3 – 70 Fixed data-1 (NTSC model) /
VCO adj. (LCD) (PAL model)
A4 80 80 V-COM adj. (LCD)
A5 30/20 30/20 RGB AMP adj. (LCD) (Note 3)
A6 Fixed data-1 (Initialized data)
A7 C0/80 C0/80 COM AMP adj. (LCD) (Note 3)
A8 80 80 White balance adj. (LCD)
A9 80 80
AA 50/30 50/30 Contrast adj. (LCD) (Note 3)
AB Fixed data-1 (Initialized data)
AC Fixed data-2
AD
AE to B3 Fixed data-1 (Initialized data)
B4 Fixed data-2
B5
B6
B7, B8 Fixed data-1 (Initialized data)
B9 Fixed data-2
BA
BB to C3 Fixed data-1 (Initialized data)
C4 Fixed data-2
C5 Fixed data-1 (Initialized data)
C6 Fixed data-2
C7 to CF Fixed data-1 (Initialized data)
D0 Fixed data-2
D1
D2, D3 Fixed data-1 (Initialized data)
D4 Fixed data-2
D5
D6
D7
D8 to FF Fixed data-1 (Initialized data)
