6-12
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R847 1-216-819-11 METAL CHIP 680 5% 1/16W
R848 1-216-820-11 METAL CHIP 820 5% 1/16W
R849 1-216-820-11 METAL CHIP 820 5% 1/16W
R850 1-216-853-11 METAL CHIP 470K 5% 1/16W
R851 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R852 1-216-845-11 METAL CHIP 100K 5% 1/16W
R853 1-216-845-11 METAL CHIP 100K 5% 1/16W
R856 1-216-845-11 METAL CHIP 100K 5% 1/16W
R857 1-216-841-11 METAL CHIP 47K 5% 1/16W
R858 1-218-879-11 RES, CHIP 22K 0.50% 1/16W
R860 1-218-883-11 RES, CHIP 33K 0.50% 1/16W
R862 1-218-897-11 RES, CHIP 120K 0.50% 1/16W
R863 1-218-897-11 RES, CHIP 120K 0.50% 1/16W
R864 1-216-864-11 METAL CHIP 0 5% 1/16W
R865 1-216-835-11 METAL CHIP 15K 5% 1/16W
R866 1-216-845-11 METAL CHIP 100K 5% 1/16W
R867 1-216-841-11 METAL CHIP 47K 5% 1/16W
R868 1-216-845-11 METAL CHIP 100K 5% 1/16W
R869 1-216-845-11 METAL CHIP 100K 5% 1/16W
R870 1-216-845-11 METAL CHIP 100K 5% 1/16W
R871 1-216-841-11 METAL CHIP 47K 5% 1/16W
R872 1-218-893-11 RES, CHIP 82K 0.50% 1/16W
R873 1-216-845-11 METAL CHIP 100K 5% 1/16W
R874 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R875 1-216-833-91 RES, CHIP 10K 5% 1/16W
R876 1-218-877-11 RES, CHIP 18K 0.50% 1/16W
R877 1-218-852-11 RES, CHIP 1.6K 0.50% 1/16W
R878 1-218-897-11 RES, CHIP 120K 0.50% 1/16W
R879 1-218-882-11 RES, CHIP 30K 0.50% 1/16W
R880 1-218-879-11 RES, CHIP 22K 0.50% 1/16W
R881 1-218-891-11 RES, CHIP 68K 0.50% 1/16W
R887 1-216-864-11 METAL CHIP 0 5% 1/16W
R888 1-216-864-11 METAL CHIP 0 5% 1/16W
R889 1-216-864-11 METAL CHIP 0 5% 1/16W
R901 1-216-845-11 METAL CHIP 100K 5% 1/16W
R902 1-216-845-11 METAL CHIP 100K 5% 1/16W
R903 1-216-845-11 METAL CHIP 100K 5% 1/16W
R904 1-216-845-11 METAL CHIP 100K 5% 1/16W
R905 1-216-845-11 METAL CHIP 100K 5% 1/16W
R906 1-216-845-11 METAL CHIP 100K 5% 1/16W
R908 1-216-864-11 METAL CHIP 0 5% 1/16W
R909 1-218-872-11 RES, CHIP 11K 0.50% 1/16W
R910 1-216-847-11 METAL CHIP 150K 5% 1/16W
R911 1-216-813-11 METAL CHIP 220 5% 1/16W
R912 1-216-845-11 METAL CHIP 100K 5% 1/16W
R913 1-216-864-11 METAL CHIP 0 5% 1/16W
R914 1-216-833-91 RES, CHIP 10K 5% 1/16W
R915 1-216-833-91 RES, CHIP 10K 5% 1/16W
R916 1-216-853-11 METAL CHIP 470K 5% 1/16W
R917 1-216-864-11 METAL CHIP 0 5% 1/16W
R918 1-216-841-11 METAL CHIP 47K 5% 1/16W
R919 1-216-864-11 METAL CHIP 0 5% 1/16W
R922 1-216-833-91 RES, CHIP 10K 5% 1/16W
R923 1-216-833-91 RES, CHIP 10K 5% 1/16W
R951 1-216-845-11 METAL CHIP 100K 5% 1/16W
R952 1-216-833-91 RES, CHIP 10K 5% 1/16W
R953 1-216-833-91 RES, CHIP 10K 5% 1/16W
R954 1-216-853-11 METAL CHIP 470K 5% 1/16W
R955 1-216-845-11 METAL CHIP 100K 5% 1/16W
R957 1-216-864-11 METAL CHIP 0 5% 1/16W
R958 1-216-821-11 METAL CHIP 1K 5% 1/16W
R959 1-216-853-11 METAL CHIP 470K 5% 1/16W
R960 1-216-849-11 METAL CHIP 220K 5% 1/16W
R961 1-216-845-11 METAL CHIP 100K 5% 1/16W
R962 1-216-845-11 METAL CHIP 100K 5% 1/16W
R963 1-216-853-11 METAL CHIP 470K 5% 1/16W
R964 1-216-845-11 METAL CHIP 100K 5% 1/16W
< SHOCK SENSOR >
SE901 1-801-868-41 SENSOR, SHOCK
< TRANSFORMER >
! T801 1-429-565-21 TRANSFORMER, CONVERTER
< VIBRATOR >
X003 1-781-457-21 OSCILLATOR, CRYSTAL (24.375MHz)
X004 1-781-456-21 OSCILLATOR, CRYSTAL (24.545451MHz)
X301 1-767-450-11 VIBRATOR, CERAMIC (20MHz)
X302 1-760-458-21 VIBRATOR, CRYSTAL (32.768kHz)
X401 1-781-413-21 VIBRATOR, CRYSTAL (12.9024MHz)
X501 1-781-160-21 VIBRATOR, CERAMIC (16.384MHz)
X901 1-781-455-21 VIBRATOR, CRYSTAL (48MHz)
A-7074-015-A FU-135 BOARD, COMPLETE (FD83)
A-7074-009-A FU-137 BOARD, COMPLETE (FD88)
**********************
(Ref.No.: 2,000 Series)
< CONNECTOR >
* CN051 1-760-388-11 CONNECTOR PIN (SMD) 9 PIN
CN052 1-691-344-11 CONNECTOR, FFC/FPC (ZIF) 6P
< FUSE >
! F051 1-576-286-21 FUSE, MICRO (1.4A/24V)
! F052 1-576-286-21 FUSE, MICRO (1.4A/24V)
! F053 1-576-286-21 FUSE, MICRO (1.4A/24V)
! F054 1-576-286-21 FUSE, MICRO (1.4A/24V)
< FERRITE BEAD >
FB051 1-414-228-11 INDUCTOR CHIP 0uH
FB052 1-414-228-11 INDUCTOR CHIP 0uH
< FILTER >
LF051 1-411-957-11 FILTER, COMMON MODE
A-7074-017-A PK-47 BOARD, COMPLETE (CASIO) (FD83)
*********************
(Ref.No.: 2,000 Series)
< CAPACITOR >
C601 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C603 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C604 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C605 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
FC-70 FU-135/FU-137 PK-47
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
