6-13
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C608 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C609 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C611 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C801 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C802 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C807 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C808 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C809 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C810 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C811 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C812 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C813 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C814 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C815 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C816 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C851 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C852 1-113-981-11 TANTAL. CHIP 22uF 20% 20V
C853 1-163-081-00 CERAMIC CHIP 0.22uF 25V
C854 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C855 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C856 1-162-918-11 CERAMIC CHIP 18PF 5% 50V
C857 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C858 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C859 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C861 1-104-911-11 TANTAL. CHIP 33uF 20% 10V
C862 1-164-346-11 CERAMIC CHIP 1uF 16V
C863 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C864 1-164-661-11 CERAMIC CHIP 0.018uF 10% 50V
C865 1-107-725-11 CERAMIC CHIP 0.1uF 10% 16V
! C866 1-113-521-11 CERAMIC CHIP 12PF 10% 3KV
C901 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C902 1-107-687-11 TANTAL. CHIP 3.3uF 20% 20V
C903 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C904 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C905 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C906 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C907 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C908 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C909 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C910 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C911 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C912 1-162-926-11 CERAMIC CHIP 82PF 5% 50V
C913 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C916 1-107-689-21 TANTAL. CHIP 1uF 20% 35V
C917 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
C918 1-107-682-11 CERAMIC CHIP 1uF 10% 16V
C919 1-107-826-91 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN601 1-764-526-11 CONNECTOR, FFC/FPC 18P
* CN602 1-750-075-11 CONNECTOR, FFC/FPC 10P
CN603 1-785-482-41 CONNECTOR, BOARD TO BOARD 70P
CN701 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN801 1-766-348-21 CONNECTOR, FFC/FPC 18P
CN851 1-691-384-11 CONNECTOR, FFC/FPC 20P
CN901 1-691-388-11 CONNECTOR, FFC/FPC 24P
< DIODE >
D601 8-719-049-09 DIODE 1SS367-T3SONY
D705 8-719-061-82 DIODE TLSU1002 (TPX1, SONY) (ACCESS)
D708 8-719-061-81 DIODE TLYU1002 (TPX1, SONY)
(FLASH/CHARGE)
D709 8-719-064-05 DIODE TLGU1002 (TPX1, SONY) (POWER)
D801 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D802 8-719-045-87 DIODE MA4Z082WA-(TX).SO
D852 8-719-073-01 DIODE MA111-(K8).S0
D853 8-719-073-01 DIODE MA111-(K8).S0
D901 8-719-073-01 DIODE MA111-(K8).S0
D902 8-713-102-80 DIODE 1T369-01-T8A
D903 8-719-976-96 DIODE MA8047-H-TX
< FERRITE BEAD >
FB601 1-414-226-21 INDUCTOR CHIP 0uH
< IC >
IC601 8-759-591-15 IC TB6055F (EL)
IC801 8-759-530-19 IC MB40D001PFV-G-BND-ER
IC802 8-759-539-27 IC IR3Y37A4
IC803 8-759-196-97 IC TC7SH32FU-TE85R
IC851 8-759-521-35 IC TL5001CDR
IC852 8-759-075-70 IC TA75S393F-TE85R
IC901 8-759-530-20 IC CM7017L3-T4
IC902 8-759-327-01 IC NJM062V (TE2)
< COIL >
L801 1-414-757-11 INDUCTOR 100uH
L802 1-414-078-11 INDUCTOR 10uH
L851 1-414-396-21 INDUCTOR 4.7uH
L852 1-424-674-11 INDUCTOR 22uH
L853 1-409-536-41 INDUCTOR 150uH
L901 1-414-754-11 INDUCTOR 10uH
L902 1-414-754-11 INDUCTOR 10uH
L903 1-412-951-11 INDUCTOR 10uH
L904 1-414-754-11 INDUCTOR 10uH
L905 1-412-953-11 INDUCTOR 15uH
< TRANSISTOR >
Q601 8-729-017-61 TRANSISTOR 2SB1581-T1
Q602 8-729-037-53 TRANSISTOR 2SB1462J-QR (K8).SO
Q603 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q604 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q851 8-729-042-72 TRANSISTOR UN9214J-(K8).SO
Q852 8-729-042-59 TRANSISTOR UN9112J-(K8).SO
Q853 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q854 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q855 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q856 8-729-823-84 TRANSISTOR FP102-TL
Q857 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q858 8-729-037-52 TRANSISTOR 2SD2216J-QR (K8).SO
Q859 8-729-037-74 TRANSISTOR UN9213J-(K8).SO
Q860 8-729-039-43 TRANSISTOR FP216-TL
The components identified by
mark ! or dotted line with
mark ! are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
PK-47
