Configuration example using a simple-type transition control block
a AUX
bus control block (see page 40)
A cross-point module
connected in an AUX bank row is
used as an AUX bus control block.
The number of cross-point buttons varies depending on
th
e module. The MKS-X7017 has 36, the MKS-X7018
has 28, and the MKS-X7019 has 20.
b AUX
bank
Up to two AUX bank rows (AUX 1, AUX 2) can be
co
nfigured.
For details, see “Assigning a Switcher Bank/AUX”
(page 395).
c M/E banks (sw
itcher banks)
You can assign switcher banks (M/E-1 to M/E-5, P/P) to
up
to six M/E bank rows.
For details, see “Assigning a Switcher Bank/AUX”
(page 395).
d Cross-
point control block (see page 18)
A cross-point module
connected in an M/E bank row is
used as a cross-point control block.
The number of cross-point buttons varies depending on
th
e module. The MKS-X7017 has 36, the MKS-X7018
has 28, and the MKS-X7019 has 20.
e T
ransition control block (see page 22)
Transition control block modules are enabled only when
connect
ed in an M/E bank row.
f Fl
exi Pad control block (see page 27)
Flexi Pad control block modules a
re enabled only when
connected in an M/E bank row.
g Numeric
keypad control block (see page 37)
Up to one numeric keypad control block module can be
connect
ed.
h Utility/shot
box control block (see page 39)
Up to two utility/shotbox control block modules can be
connect
ed.
i De
vice control block (see page 33)
Up to one device control block
module can be connected.
j K
ey control block (see page 29)
Up to four key control block modules can be connected.
k Transi
tion control block (simple type) (see
page 25)
Transition control block (simple type) modules are
enabled onl
y when connected in an M/E bank row.
l In
dependent key transition control block (see
page 26)
Independent key transition control block modules are
enabled onl
y when connected in an M/E bank row.
m K
ey fader control block (see page 31)
Up to four key fader control block modules can be
connec
ted.
