76

Windows MAXPage Software Installation & Configuration Guide for MAXPage
Supplied with mains adapter 110-240VAC (autosensing) 50/60Hz 25W max
LCD Screen
Large backlit 16 character x 2 line screen
Keypad
19 key silicone keypad (green LED backlight)
Recipient Capacity
1000 pagers (with pager ID’s 0-9999 available)
Group Capacity
20 groups each with up to 10 members
Escalation Capacity
To second recipient after 0 - 9999 second delay
Maximum Message
Length
200 characters via keypad or keyboard
30,000 characters via serial port or Windows software
Function Keys
8 (hotkey to send canned message to recipients)
Reminder Messages
10 comprising of time, recipient and message
Common (Canned)
Messages
10
Voice Paging Sound
Input
In-built electret microphone
Voice Paging A Tone, B
Tone, Gap Limits
0.0-10.0 seconds in 0.1 increments
Supported Input
Protocols
TAP (PET / IXO), ESPA, Comp1, Comp2, Scope, Tekk, Visiplex#1
Supported Output
Protocols
POCSAG 512/1200/2400bps
Dimensions
226 x 160 x 70 mm / 8.9 x 6.3 x 2.75 inches
Weight
1.0kg / 2.2lb nett
Ambient Temperature
Operating Range
0 to -50°C (20-90% RH non condensing)
Storage Temperature
Range
-10 to 60°C (10-95% RH non condensing)
