spok MAXPage - Technical Specifications

Installation & Configuration Guide for MAXPage Windows MAXPage Software

75
Tone No.
Reed Group 1
Reed Group 2
Reed Group 3
Reed
Code
Frequency
Hz.
Reed
Code
Frequency
Hz.
Reed
Code
Frequency
Hz.
1
111
349.0
121
600.9
138
288.5
2
112
368.5
122
634.5
108
296.5
3
113
389.0
123
669.9
139
304.7
4
114
410.8
124
707.3
109
313.0
5
115
433.7
125
746.8
160
953.7
6
116
457.9
126
788.5
130
979.9
7
117
483.5
127
832.5
161
1006.9
8
118
510.5
128
879.0
131
1034.7
9
119
539.0
129
928.1
162
1063.2
0
110
330.5
120
569.1
189
1092.4
Tone No.
Reed Group 4
Reed Group 5
Reed Group 6
Reed
Code
Frequency
Hz.
Reed
Code
Frequency
Hz.
Reed
Code
Frequency
Hz.
1
141
339.6
151
584.8
191
1153.4
2
142
358.6
152
617.4
192
1185.2
3
143
378.6
153
651.9
193
1217.8
4
144
399.8
154
688.3
194
1251.4
5
145
422.1
155
726.8
195
1285.8
6
146
445.7
156
767.4
196
1321.3
7
147
470.5
157
810.2
197
1357.6
8
148
496.8
158
855.5
198
1395.0
9
149
524.6
159
903.2
199
1433.4
0
140
321.7
150
553.9
190
1122.5
NOTE: There are two other tone groups 11 and 12 that are rarely used.
Technical Specifications
Specifications are subject to change without notice.
Equipment Type
Desktop POCSAG paging encoder/transmitter
Internal Transmitter
Adjustable from 100mW-5W (4W default)
Frequency Range
VHF 148-174MHz. UHF 440-470MHz Synthesized
LED Indicators
Power, Transmit, PBX
External Connectors
Antenna: TNC F 50Ω
Telephone: RJ12F Non-powered FXO analogue port
Serial: DB9F RS232C 300-57600 Baud (default 9600bps)
Keyboard: PS2F option to enter alpha-numeric characters
Alarm Inputs: RJ45F 1-4 dry contact inputs with common ground
Power Supply
12VDC @ 2Amps regulated via 2.1mm DC socket
