35
Using the Telephone (PBX) interface
To use MAXPage’s Telephone interface follow the directions below.
1. Pick up the phone and dial the extension to which the MAXPage is connected. After a short pause, you hear
“Enter pager number.”
2. Type the Pager ID of the pager or group you wish to contact.
NOTE: If the Pager ID has fewer characters than the PBX Digits field above, the Pager ID has to be typed in with
leading zeroes. Alternatively, the # key is a termination key which enters the Pager ID.
Example: If PBX digits is set to 4 and you want to send a message to Pager ID ‘1’ you can type 0004 or 1 followed
by the # key.
3. After the Pager ID has been entered, you hear “Enter Message.” Using the numeric keypad on the phone,
type the message you wish to send.
4. If you want to insert a canned message during a telephone call, simply press the * key followed by the
number assigned to the canned msg, followed by the # key to end the message. The message is sent.
NOTE: You can combine canned messages with other numbers. For example you could have canned message #1 set
to “call extension”. When prompted to “Enter Message” you would type *134#. This would send the message “call
extension34”. Canned msg’s are explained in more detail below in the Canned Msgs section.
RS232
This menu is used to configure options specific to the RS232 interface. The settings within the following menus
must match that of the device connected to the MAXPage unit.
NOTE: The “RS232” menu item may not be available on all units as it is a licensed option. Contact your place of
purchase to enable this function.
1. In the Config Mode screen, press to choose RS232. The following screen displays.
1.Communications
2.Protocol
2. In the RS232 Menu screen, choose one of the following options:
a. The Communications option configures the serial port properties such as baud rate and flow control.
b. The Protocol option is used to choose and configure from several different paging protocols.
Communications
1. To choose Communications, press from the RS232 Menu. The Communications Menu screen
displays.
Baud rate[9600 ]
Parity [NONE]
2. The first field for editing is the Baud Rate. Press any numeric key on the keypad to toggle between 300,
600, 1200, 2400, 4800, 9600, 19200, 38400 or 57600 bps.
3. Press the key to move along to the next field.
4. The next field is Parity. Press any key on the keypad to toggle between NONE, ODD or EVEN here.
