General Operation Installation & Configuration Guide for MAXPage
5. Press the key to move along to the next screen.
6. The first field on this next screen is Data. This refers to the “data bit” property of the RS232 connection.
Press a key on the keypad to choose between 7 or 8 here.
7. Press the key to move along to the next field.
Data[8] Stop[1]
Flow Ctrl [NONE]
8. The next field along is Stop. This refers to the “stop bit” property of the connection.
9. Press a key on the keypad to choose between 1 or 2 here.
10. Press the key to move along to the next field.
11. The next field along is Flow Ctrl. This refers to the “flow control” property of the connection. Press any
key on the keypad to choose between NONE, HARD, or SOFT. (None, Hardware flow control, Software
flow control).
12. Press the key to move along to the next field saving changes when ready. You are taken back to the first
screen of the RS232 Menu.
13. To return to Normal Mode, press the key four times to exit out of all menus. MAXPage restarts and is
ready for use.
Protocol
1. To choose, Protocol press from the RS232 Menu. The Protocol Menu screen displays.
Protocol [ ]
Lookup ID? [N]
2. The first field for editing is Protocol. If you are connecting MAXPage to another piece of paging
equipment that uses the TAP, COMP1, COMP2, Tekk, Visiplex#1, or SCOPE protocols, you need to
configure it in this field. Press any key on the keypad to choose between TAP, COMP1, COMP2, Tekk,
Vplex, ESPA or SCOPE.
3. Press the key to move along to the next field.
4. This next field is Lookup ID. Press any key on the keypad to toggle between Y or N (Yes or No) here.
a. Setting to Y means that the TAP message contains a Pager ID. MAXPage looks up the Pager ID within
its internal database and send the message to the appropriate recipient.
b. Setting to N means that the TAP message contains a cap code. MAXPage sends the message to the cap
code specified.
5. Press the key to move along to the next screen when ready.
NOTE: When serial input from a COMP2 or TAP third party paging system is being utilized and the Lookup ID?
Field is set to N, a raw cap code is being supplied within the protocol data rather than a Pager ID. Therefore there is
no way MAXPage can determine how to encode the message. This default encoding method is set in the Encoding
field described in the Transmitter section.
6. The next screen that is displayed is dynamic, depending on which protocol is chosen in the Protocol field
above. This is described in more detail below.
TAP
