12.4 Connection data
12.4.1 Electrical connections
Voltage sources
Consumer Voltage
[Volt]
Direct connection
to the tractor battery
Power socket
Lighting equipment 12 - According to DIN ISO 1724
Lighting equipment
(Canada, USA)
12 - According to ISO 1185
ISOBUS socket 12 ● According to DIN 11783
Voltage tolerance range: 10 V to 15 V
12.4.2 Hydraulic connections
Hydraulic connections and control units
Consumer DW EW EW+T LS+P+T Colour
Pressure - - ● - Yellow
Hydraulic elements: Pressure and lifting ● - - - Green
EW = single-acting control unit
EW+T = single-acting control unit, ow of oil to the tank
DW = double-acting control unit
LS+P+T = Load Sensing, ow of oil to the pump and ow of oil to the tank
12.5 Noise, airborne sound
Noise level of the implement while working
£70 dB(A)
Technical data
en-GB | Item no. 17513597 | BA 02/05-2022 115
