Hoses and lines of hydraulically operated hoeing implements:
3
1
2
4
5
6
7
1
Hose for Load Sensing: LS
2
Hose for Load Sensing: Pressure ("P")
3
Hose for Load Sensing: Return ("T")
4
ISOBUS line
5
CAN bus line
6
Pressure sensor line
7
Hoses for the pressure system of the hydraulically liftable elements
INFORMATION
Not shown:
– Line for lighting equipment
– Hoses for further hydraulic functions
The functions are distinguished by the plug colours.
Ä Chapter 12.4.2 ‘Hydraulic connections’ on page 115
3.2 Machine safety
3.2.1 Meaning of the labels
This section explains the information and warning signs that have been
axed to the machine.
Hydraulic hoses and lines
Design and description
en-GB | Item no. 17513597 | BA 02/05-2022 21
