Hydraulically operated hoeing machine have the following electro-
hydraulic devices:
Housing for job computer, central control valve and other hydraulic
components
Lever for ball valve "LS"
Pressure gauge
Oil pressure accumulator for hydraulic pressure
Oil pressure accumulator for lifting function
Lever for ball valve "B"
ATTENTION
Keep ball valve "B"
closed. The pressure gauge and
other parts of the hydraulic system can be destroyed by
overpressure.
INFORMATION
Keep the housing
for the job computer and the con‐
trol valve closed. Only service personnel may open the
housing.
Electro-hydraulic devices
Design and description
