6.2.3 Lifting and lowering hoeing elements hydraulically
The following hoeing elements are lifted or lowered hydraulically:
n Combi-Elements with hydraulic ram
n Finger weeder arms with hydraulic ram (only in combination with
hydraulic Combi-Elements)
1
2
1
Combi-Elements with hydraulic ram for hydraulic movement
2
Finger weeder arm with hydraulic ram for hydraulic movement
Combi-Element and nger weeder arm are always moved together.
The hydraulic operation of the hoeing elements takes place via the con‐
trol Section Control. The targeted lifting and lowering of the individual
hoeing elements is done at the touch of a button.
Ä Chapter 3.8.2 ‘Operating menu of Section Control’ on page 39
Ä Chapter 6.3.7 ‘Setting menus of Section Control ’ on page 87
Operate hoeing elements
Operation
