6.2.2.3 Lift nger weeder arm mechanically
Finger weeders are mounted as trailing tools on spring-loaded arms. If
the nger weeders are not needed, the double spring arms with the
mounted nger weeders can be folded up in two steps.
1
2
Left: Finger weeder arm in operating position. Middle: Arm raised to middle position. Right: Arm raised to top position.
1
Double spring arm
2
Handle
To move the double spring arm
1
:
1.
Pull out the handle
2
with the pin
3
slightly.
CAUTION: Risk of being crushed due to the dead weight of the
element
n Do NOT touch the shearing points of a moving component.
n Hold the element rmly.
2. Move the arm in the desired direction.
3.
Let the pin engage in the bottom
3
, middle
4
or top
5
position.
5
4
3
3
Pin, bottom position
4
Opening for pin, middle position
5
Opening for pin, top position
Operation
