Steketee EC-WEEDER - Symbols and Text Markings

Signal word Meaning
NOTE Indicates tips and useful information for the
user
ENVIRONMENTAL
PROTECTION
Indicates notices and special measures
regarding environmental protection
1.3.2 Symbols and text markings
Symbol, text
marking
Meaning
In front of and in texts
● Marking for routine maintenance tasks
Activities that demand the help of service
sta.
n
Listing
[1], ,
Position numbers
Example: ‘Settings’ Software element
Example: [OK] Softkey, key, switch and button
[kg] Unit
Ä
Cross reference
In work instructions
√ Preconditions
► n Working steps in single-step work
instructions
n Measures for hazard avoidance in safety
information
1.
2.
Working steps in multi-step work instructions
ð
Result
In illustrations
Light grey coloured
components
Non-relevant components, visible to facilitate
orientation
Yellow coloured com‐
ponents
Action-relevant components
Other notices and information
