DESCRIPTION
39
764333-099
FIG. &
ITEM
NO.
PART
NUMBER
UNITS PER
ASSEMBLY
19 RECIRCULATION PUMP SYSTEM AND SELF-CLEANING FILTER
One Tank ........................................................................................ X
Two Tanks...................................................................................... X
1 P 117940 999 BOLT, Steel, 5/8"-11 x 2-1/2", Plated................................................... 4 8
2 P 117940 702 LOCKWASHER, Steel, 5/8", Plated..................................................... 4 8
3 P 117940 701 NUT, Steel, 5/"8-11, Plated.................................................................. 4
4 P 117940 019 GASKET, Teflon, 2" Ø ........................................................................ 1
5 P 117041 836 FILTER, Self-Cleaning ......................................................................... 1
6 P 117044 493 CARTRIDGE, Filter, Self-cleaning ....................................................... 1
7 P 117940 292 HOSE, 1/2"........................................................................................... 30"
8 P 117950 674 CLAMP, S/S, #24, 1-1/16" @ 2"........................................................... 4
9 P 117940 020 PRESSURE GAUGE, 0-60 PSI, 1/4" ................................................... 1
10 P 117997 591 VALVE, Pneumatic, Ball, 2" ................................................................ 1
11 P 117942 756 • KIT, Repair, For Valve 117997-591 .................................................. 1
12 P 117909 604 VALVE, Pneumatic, Ball, 1" ................................................................. 3 4
13 P 117943 208 • KIT, Repair, For Valve 117909-604 .................................................. 3 4
14 P 117941 438 HOSE, 3-1/2 x 4".................................................................................. 1
15 P 117950 792 CLAMP, S/S, #64, 3-9/16" @ 4-1/2" .................................................... 4
16 P 117943 319 PUMP, 10hp 208/230/460V D824F 9H WORTH (See Figure 16) ....... 1
17 P 117955 591 FITTING, Compression, S/S, 1/8" M X 1/8 OD .................................... 1
18 P 117909 491 PLUG, S/S, 1/8" M, Hexagonal Head .................................................. 1
19 P 117940 805 RTD...................................................................................................... 1
20 P 117953 969 CAP, 1-1/2" .......................................................................................... 1 2
21 P 117913 069 SENSOR, Conductivity, 200 pH........................................................... 1
22 P 117912 269 CABLE, Sensor, Thornton, 10'............................................................. 1
23 P 117041 949 HOSE, Pop Up ..................................................................................... 1
24 P 117044 130 HOSE, Drain, Flexible .......................................................................... 1
25 P 117041 924 HOSE, Flexible, Tank 1 & 2 ................................................................. 1 2
26 P 117951 387 CLAMP, Quick-Disconnect, 3" (Not Shown) ........................................ A/R
27 P 117953 306 O-RING, Tri-Clamp, 1/2", Silicone (Not Shown)................................... A/R
28 P 117950 808 CLAMP, Quick-Disconnect, 2" (Not Shown) ........................................ A/R
29 P 117951 568 GASKET, Silicone, 2" (Not Shown)...................................................... A/R
30 P 117951 196 CLAMP, Quick-Disconnect, 1-1/2" (Not Shown) .................................. A/R
31 P 117953 306 GASKET, Silicone, 1-1/2" (Not Shown) ............................................... A/R
32 P 117906 173 SOLUTION, Conductivity, 84 uS/cm (Not Shown) ............................... 1
33 P 117906 175 SOLUTION, Conductivity, 5000 uS/cm (Not Shown) ........................... 1
34 P 117940 018 GASKET, Teflon, 3" Ø ......................................................................... 1
35 P 117943 286 VALVE, Ball, Man., S/S, 3/8" ............................................................... 1
36 P 117010 270 NOZZLE, Valve, Sampling................................................................... 1
37 P 117997 590 VALVE, Pneumatic Ball, Assembly, 1-1/2" .......................................... 1
38 P 117912 699 KIT, Repair, RKP154 for Actuator ........................................................ 1
P 117943 209 • KIT, Repair, #RKN111TT for Valve 1-1/2"
